Ridgid K-40 Replacement Parts List

1-1

Frame Assembly Part # 71887 Currently not available

N/A
1-2

Screw 10 - 24 X 3/8" Part # 45420 Currently not available

N/A
1-3

Rubber Foot (2) Part # 71972 Currently not available

N/A
1-4

Carriage Bolt 5/16 - 18 X 3/4 (3) Part # 96260 Currently not available

N/A
1-5

Flange Bearing (2) Part # 71967 Currently not available

N/A
1-6

Drum Shaft Part # 71942 Currently not available

N/A
1-7

Ring, Retaining KM26B Part # 59810 Currently not available

N/A
1-8

Tip, Rubber Part # 37962 Currently not available

N/A
1-9

Fan Part # 73997 Currently not available

N/A
1-10

Motor Pulley f/144XL Belt Part # 71947 Currently not available

N/A
1-00

Motor Pulley f/160XL Belt Part # 32638 Currently not available

N/A
1-11

Main Pulley Part # 71952 Currently not available

N/A
1-00

Main Pulley (230V 50Hz Only) Part # 83912 Currently not available

N/A
1-12

Drive Belt (144XL) Part # 32643 Currently not available

N/A
1-00

Drive Belt (160XL) Part # 71957 Currently not available

N/A
1-00

Drive Belt (230V 50Hz Only) Part # 83917 Currently not available

N/A
1-13

Screw #10-32 X 1/2" Button Head (2) Part # 35217 Currently not available

N/A
1-14

Motor Mounting Plate Part # 71977 Currently not available

N/A
1-15

Flat Washer 5/16" Part # 60065 Currently not available

N/A
1-16

Hc Washer .515X.875X.032 *tbo Part # 60080 Currently not available

N/A
1-17

Hex Nut 5/16 - 18 (3) Part # 60230 Currently not available

N/A
1-18

Screw 10 - 24 X 3/8" Part # 45420 Currently not available

N/A
1-19

Motor 115V 60Hz Part # 71982 Currently not available

N/A
1-00

Motor 230V 50Hz Part # 72017 Currently not available

N/A
